This series of weighers are designed to work as a twin weigher for doubling the speed. It contents:
-16head, 18head, 20head, 24head, 30head weigher.
-The hopper volume: 0.5Litre, 1.6Litre, 2.5Litre,
-Software: Generation 2.5 and 4.0
-Display: 10.4 inch touch screen, with 3 different languages.
-Discharge points: 1 upto 5, depends on client's request.
Application:
This automatic weighing machine is suitable for almost all solid type products with sizes range from 1 mm upto 70 mm! Such as: salt, sugar, rice, snacks, candies, nuts, fruits, puffed products, chips, dry fruits, biscuits, cookies and so on!
Contact us to Choose correct model!
Feature:
-User friendly design, smart functions!
-Very stable quality with good performance!
-Stagger dumps function to avoid big products stuck!
-Multiple dumps function to allow weighing big weight up to 5kg, 10kg and more!
-When there is lack of products, this weigher will stop automatically, when there comes enough products, the weigher will start to work again automatically!
Option:
-Use load cell to control the feeding from elevator
-Contacting parts can be changed to:
a. dimple plate
b. teflon coated
c. change from s.s.304 to s.s.316 for corrosive products
-Add Reject device to reject unqualify dumps
-Add diverter devices to allow semi-automatic packaging, packaging manually.
-110V, 220V, 380V, 50Hz 60Hz for options!
Specifications:
Item | High Speed 18-Head Weigher With Memory Hopper | 24 Heads Blending Weigher With Memory Hopper | 30 Heads Blending Weigher With Memory Hopper |
Model | AT18H-19 | AT24H-19 | AT30H-19 |
Generation | 4.0G Plus | 4.0G Plus | 4.0G Plus |
Weighing Range | 15g~500g | 15g~500g | 15g~500g |
Max.speed | 200 WPM or 3X60 WPM | 240 or 4x60 WPM | 300 or 5x60 WPM |
Power Supply | 220V,50/60HZ,3kW | 220V,50/60HZ,4.0kW | 220V,50/60HZ,4.5kW |
Hopper Volume | 0.8L | 0.8L | 0.8L |
Monitor | 10.4 inches color touch screen | ||
Dimension( mm) | 2000×1550×1700 | 1966×1966×1584 | 2270×2270×2188 |
